Electronic Devices PYQJEE Main 2022 (Online) 28th July Morning Shift
Identify the solar cell characteristics from the following options :
Solution
Correct option: B
Correct option: B
Step 1
A solar cell works as a photovoltaic device, so its characteristic curve lies in the power-producing region of the diode graph.
Step 2
For a solar cell, current is available even when the external voltage is zero, and a finite open-circuit voltage exists when current becomes zero.
Step 3
The correct graph must therefore show the solar-cell I-V characteristic in the fourth quadrant, with non-zero short-circuit current and open-circuit voltage.
Step 4
Among the given graphs, this behaviour matches option B.
