Geometrical Optics PYQJEE Advanced 2022 Paper 2 Online

INTEGER+3 / -12022

Consider a configuration of n identical units, each consisting of three layers. The first layer is a column of air of height h=13 cm, and the second and third layers are of equal thickness d= 3−12 cm, and refractive indices μ1=32 and μ2=3, respectively. A light source 0 is placed on the top of the first unit, as shown in the figure. A ray of light from 0 is incident on the second layer of the first unit at an angle of θ=60∘ to the normal. For a specific value of n, the ray of light emerges from the bottom of the configuration at a distance l=83 cm, as shown in the figure. The value of n is ________.


JEE Advanced 2022 Paper 2 Online Physics - Geometrical Optics Question 30 English

More Geometrical Optics questions to practice

Question details

Source: JEE Advanced 2022 Paper 2 Online. Subject: Physics. Chapter: Geometrical Optics. Marking: +3 / -1.

Geometrical Optics has 70 previous-year questions in JEE Advanced since 1978. It appeared in 51.4% of the 74 papers analysed. In 2026 it averaged 1.5 questions per paper, about 8.8% of the paper.
