Rotational Motion PYQIIT-JEE 2011 Paper 1 Offline
A metal rod of length L and mass m is pivoted at one end. A thin disk of mass M and radius R ( < L) is attached at its centre to the free end of the rod. Consider two ways the disc is attached : (case A). The disc is not free to rotate about its centre and (case B) the disc is free to rotate about its centre. The rod-disc system performs SHM in vertical plane after being released from the same displaced position. Which of the following statement(s) is(are) true?

Solution
Correct option: A, D
Correct options: A, D
Compare the restoring torque
For the same angular displacement, gravity acts on the rod and on the disk in the same way in both cases. Hence the restoring torque is identical:
Moment of inertia in case A
When the disk cannot spin about its own centre, its own rotational inertia also contributes:
Moment of inertia in case B
When the disk is free to rotate about its centre, its spin inertia does not affect the oscillation about the pivot:
Compare angular frequencies
For small oscillations,
Since the restoring torque is the same but
Thus statements A and D are true.
