Electromagnetic Induction PYQMHT CET 2022 11th August Evening Shift
A graph of magnetic flux

Solution
Correct option: D
Inductor A has the largest self-inductance.
Recall flux relation
For an inductor, magnetic flux and current are related by
Connect slope with inductance
Rearranging,
So, on a
Compare the lines
To compare slopes, take the same current value for all four lines and compare the corresponding flux values.
Choose maximum slope
The line marked A has the greatest slope, hence it has the largest self-inductance.
Therefore, the correct option is D.
