Electronic Devices PYQJEE Main 2023 (Online) 30th January Morning Shift
The output waveform of the given logical circuit for the following inputs A and B as shown below, is :

Solution
Correct option: D
The circuit behaves as an AND gate, so the output is high only during the common high portions of A and B. Hence, the correct waveform is option D.
Identify the Gate
The given diode logic circuit is equivalent to an AND gate.
Write the Logic
For an AND gate, the output is
Apply the Input Waveforms
Check each time interval:
Match the Option
The waveform with pulses only in the overlapping high regions of A and B is shown in option D.
