Four identical thin, square metal sheets, $S_1, S_2, S_3$ and $S_4$, each of side $a$ are kept parallel to each other with equal distance $d(\ll a)$ between them, as shown in the figure. Let \({C_0} = {{{\varepsilon _0}{a^2}} \over d}\), where $\varepsilon_0$ is the permittivity of free space.



JEE Advanced 2024 Paper 1 Online Physics - Capacitor Question 3 English

Match the quantities mentioned in List-I with their values in List-II and choose the correct option.






table {
width: 100%;
border-collapse: collapse;
}
th {
background-color: #1E90FF;
color: white;
}
th, td {
border: 1px solid lightgrey;
padding: 8px;
text-align: left;
}
body[data-theme='dark'] th, body[data-theme='dark'] td {
border: 1px solid white;
}





























List-I List-II
(P) The capacitance between $S_1$ and $S_4$, with $S_2$ and $S_3$ not connected, is (1) $3C_0$
(Q) The capacitance between $S_1$ and $S_4$, with $S_2$ shorted to $S_3$, is (2) $\frac{C_0}{2}$
(R) The capacitance between $S_1$ and $S_3$, with $S_2$ shorted to $S_4$, is (3) $\frac{C_0}{3}$
(S) The capacitance between $S_1$ and $S_2$, with $S_3$ shorted to $S_1$, and $S_2$ shorted to $S_4$, is (4) $\frac{2C_0}{3}$
(5) $2C_0$
